LED Letter Display
LED Letter Display Introduction
The LED Letter Display is a creative digital signage solution that combines bold alphabet-shaped structures with vibrant LED visuals. Each letter is independently designed and embedded with high-resolution LED modules, making it ideal for spelling out brand names, slogans, or decorative phrases in a visually striking format.
Whether used for retail storefronts, exhibitions, corporate lobbies, or event backdrops, LED letter screens attract immediate attention and offer a perfect blend of design, technology, and branding. With customizable font styles, sizes, and colors, they provide unmatched flexibility for both functional signage and creative installations.
Product description
Product Description:
The LED Letter Display turns ordinary signage into a dynamic visual statement. With customizable letter shapes and full-color LED surfaces, each unit brings messaging to life through light, motion, and form. Perfect for modern branding and interior design, it delivers both functional communication and eye-catching aesthetic appeal in any space.
Product parameters
Technical Specifications – LED Letter Display
| Parameter | Specification |
|---|---|
| Pixel Pitch | P1.5 / P2 / P2.5 / P3 / P4 / P5 (customizable based on letter size & viewing distance) |
| LED Type | SMD Full Color (1R1G1B) |
| Brightness | 800 – 1,000 nits (indoor); up to 5,000 nits for semi-outdoor use |
| Refresh Rate | ≥1920Hz standard; Optional ≥3840Hz |
| Gray Scale | 14-bit / 16-bit |
| Letter Shapes | A–Z, 0–9, special characters (fully customizable fonts and styles) |
| Material | Aluminum alloy / Acrylic / Steel frame (based on installation requirements) |
| Display Surface | Flat or curved surface depending on letter design |
| Cabinet Depth | Typically 80–150mm, customizable |
| Control System | Synchronous / Asynchronous (NovaStar / Colorlight / Huidu compatible) |
| Content Format | Video (MP4), Images (JPG, PNG), Text, Animations (GIF) |
| Installation Method | Wall-mounted, free-standing, hanging, or embedded |
| Power Supply | AC100–240V, 50/60Hz |
| Operating Temperature | -10°C to +45°C |
| Ingress Protection | IP30–IP43 (indoor); IP54 available for semi-outdoor models |
| Maintenance | Front or rear access based on structure |
| Lifespan | ≥100,000 hours |
| Certification | CE / FCC / RoHS / EMC |
